Firgelli Automations 6" Stroke Feedback Linear Actuator 150lbs Force
Product details
| Management number | 228694962 | Release Date | 2026/05/31 | List Price | $62.00 | Model Number | 228694962 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Firgelli automations rod-style linear actuators feature an electrical motor that extends and retracts a mechanical rod shaft along a straight line providing smooth, quiet motion. They are capable of pushing/pulling up to 150 lbs of force, while moving up to 0.5 inch per second at full load. These feedback actuators have built in bournes 10 turn potentiometers with 10000 ohm, resistance so you can determine the position of the actuator at any point in time. They also feature built-in limit-switches and clevis mounting points on each end for flexibility. These linear motors can be used for a wide variety of home, office or car automation projects including: a motorized cabinet or table top, display shelf riser, pop-up/drop-down tv lift, boat hatch, truck utility/toolbox or tonneau cover lift, wheelchair ramps, industrial machinery, art installations, and aerospace technology.
- Capable of 150 lbs (68 kg) of Dynamic Push/Pull Force; 300 lbs Static Force
- Operating Speed is 0.5"/Second at Full Load
- 2, 4, 6, 8 and 12" Stroke Lengths Available
- Rated IP54; Protected Against Harmful Deposits of Dust and Splashes of Water
- Built in Bournes Potentiometer Provides Position Feedback
| ASIN | B017MY86N4 |
|---|---|
| Size | 6 Inch Stroke |
| Voltage | 12 Volts |
| Material | Aluminum |
| Item Weight | 3.1 pounds |
| Part Number | FA-PO-150-12-6 |
| Manufacturer | Firgelli Automations Inc. |
| Extension Length | 17.9 Inches |
| Amperage Capacity | 5 Amps |
| Item model number | FA-PO-150-12-6 |
| Temperature Range | Negative 15 to 150 Degrees Fahrenheit |
| Batteries Included | No |
| Batteries Required | No |
| Product Dimensions | 11.9 x 1.57 x 3 inches |
| Item Package Quantity | 1 |
| Maximum Weight Capacity | 150 Pounds |
